2.1 System Configuration
2.1.6 Connecting to motion controller CPU (A273UCPU, A273UHCPU(-S3), A373UCPU(-S3))
2.1.6 Connecting to motion controller CPU
(A273UCPU, A273UHCPU(-S3), A373UCPU(-S3))
1 System configuration and connection conditions
(1) When using no extension base unit
*1 The number of connectable GOTs is limited by the type of the connected CPU and the number of the intelligent
function modules.
Section 2.3 When connecting multiple GOTs
Connection conditions
System configuration
Number of
GOTs
*1
Distance from main
base unit to 1st GOT
1
2.5m or less
More than 2.5m
2
2.5m or less
More than 2.5m
3 2.5m or less
Communication driver
Bus(A/QnA)
MAX2.5m
Connection cable
4
1
Connection cable
7
Bus connector conversion box
3
MAX2.5m
Connection cable
5
MAX32.5m
1
Connection cable
8
MAX2.5m
Connection cable
4
MAX32.5m
12
MAX2.5m
Connection
cable
7
3
Connection cable
8
MAX30m
MAX32.5m
Connection cable
5
2 1
Bus connector
conversion box
MAX2.5m
Connection
cable
8
Connection cable
8
MAX30m
MAX32.5m
Connection cable
4
2 2 1
