10.4 PLC Side Setting
KEYENCE PLC
For details of KEYENCE PLC, refer to the following manual.
User’s Manual for the KEYENCE PLC
10.4.1 Connecting KV-1000
*1 There is no transmission speed setting on the PLC side. The transmission speed of the PLC side is automatically
adjusted to that of the GOT side.
10.4.2 Connecting KV-700
Model name Reference
PLC CPU
KV-1000 Section 10.4.1
KV-700 Section 10.4.2
Multi-communication unit
KV-L20R
Section 10.4.3
KV-L20
Setting items Set value
Transmission speed
9600bps to 115200bps
*1
Data length 8 bits
Parity bit Even
Stop bit 1 bit
Setting items Set value
Transmission speed 9600bps
Data length 8 bits
Parity bit Even
Stop bit 1 bit
