21.1 System Configuration
21.1.5 Connecting to SDC40A/40B/40G
21 - 11
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
21.1.5 Connecting to SDC40A/40B/40G
1 System configuration and connection conditions
Connection conditions
System configuration
Number of
GOTs
Number of
Temperature
controllers
Communi
cation
Distance
1 1 RS-232 15m or less
1
1 RS-232 15m or less
31 (max.) RS-485 500m or less
1 15 (max.) RS-485 500m or less
1 15 (max.) RS-485 500m or less
YAMATAKE SDC/DMC
Communication driver
RS-232 cable 2)
5
1
MAX15m
4
RS-232 cable 1)
6
RS-485 cable 2)
7
1
31 (max.)
Interface converter
MAX500m
MAX15m
RS-485 cable 4)
8
2
15 (max.)
MAX500m
RS-485 cable 5)
9
3
15 (max.)
MAX500m
