11.4 PLC Side Setting
11.4.2 Connecting to JW-32CUH, JW-33CUH or Z-512J
11 - 37
9
CONNECTION TO OMRON PLC
10
CONNECTION TO KEYENCE PLC
11
CONNECTION TO SHARP PLC
12
CONNECTION TO TOSHIBA PLC
13
CONNECTION TO HITACHI PLC
14
CONNECTION TO MATSUSHITA PLC
15
CONNECTION TO YASKAWA PLC
16
CONNECTION TO YOKOGAWA PLC
11.4.2 Connecting to JW-32CUH, JW-33CUH or Z-512J
1 Settings for connecting to communication port 1 (PG/COMM1 port)
Set the system memory.
*1 This indicates only the transmission speeds that can be specified on the GOT side.
*2 Specify the transmission speed to match the transmission speed of the GOT.
For how to set the transmission speed of the GOT, refer to the following.
Section 11.3.3 Setting communication interface (Communication settings)
2 Settings for connecting to communication port 2 (PG/COMM2 port)
Set the system memory.
*3 This indicates only the transmission speeds that can be specified on the GOT side.
*4 Specify the transmission speed to match the transmission speed of the GOT.
For how to set the transmission speed of the GOT, refer to the following.
Section 11.3.3 Setting communication interface (Communication settings)
System memory No. Item Setting
#234
Transmission speed, parity and
stop bit
#235 Station No. 1: Station No. 1 (fixed)
System memory No. Item Setting
#236
Transmission speed, parity and
stop bit
#237 Station No. 1: Station No. 1 (fixed)
*1 *2
D7 D6 D5 D4 D3 D2 D0
0 0 (3) (2) (1)
(1)
(2)
(3)
Transmission speed
000: 19200bps
001: 9600bps
010: 4800bps
Parity
10 (fixed): Even
1 (fixed): 2 bits
Stop bit
*3 *4
D7 D6 D5 D4 D3 D2 D0
00
(3) (2) (1)
(1)
(2)
(3)
Transmission speed
000: 19200bps
001: 9600bps
010: 4800bps
Parity
10 (fixed): Even
1 (fixed): 2 bits
Stop bit
