21 - 4
21.1 System Configuration
21.1.2 Connecting to SDC15, SDC25/26 or SDC35/36
21.1.2 Connecting to SDC15, SDC25/26 or SDC35/36
1 System configuration and connection conditions
Connection conditions
System configuration
Number of
GOTs
Number of
Temperature
controllers
Communi
-cation
Distance
1
1 RS-232 15m or less
31 (max.) RS-485 500m or less
1 31 (max.) RS-485 500m or less
YAMATAKE SDC/DMC
Communication driver
RS-232 cable 1)
RS-485 cable 1)
1
31 (max.)
Interface converter
MAX500m
MAX15m
3
5
4
RS-485 cable 3)
2
MAX500m
31 (max.)
