3.1.7 Connecting to motion controller CPU
A motion controller CPU (Q Series) mounted to the multiple CPU system of the QCPU (Q mode) can be
monitored.
The system configuration, connection conditions, and system equipment when connecting a GOT to a
motion controller CPU (Q Series) are the same as those for the QCPU.
( Section 3.1.1 Connecting to QCPU)
The system configuration, connection conditions, and system equipment when connecting to a motion
controller CPU (A Series) are the same as those for the ACPU.
( Section 3.1.2 Connecting to QnACPU or ACPU)
3.1.8 Connecting to remote I/O station in MELSECNET/H network system
When the GOT is connected to a remote I/O station in the MELSECNET/H network system, the system
configuration, connection conditions and system equipment are identical with those in the case of QCPU
connection.
( Section 3.1.1 Connecting to QCPU)
Communication driver
A/QnA/QCPU,QJ71C24, MELDAS C6*
Communication driver
A/QnA/QCPU,QJ71C24, MELDAS C6*
