21.1 System Configuration
21.1.1 Connecting to DMC10
21.1 System Configuration
Select a system configuration suitable for your application.
Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions correspond
to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
21.1.1 Connecting to DMC10
1 System configuration and connection conditions
Connection conditions
System configuration
Number of
GOTs
Number of
temperature
controllers
Communi
-cation
Distance
1
RS-232 15m or less
15 (max.) RS-485 500m or less
1 15 (max.) RS-485 500m or less
YAMATAKE SDC/DMC
Communication driver
MAX15m
RS-232 cable 1)
MAX500m
RS-485 cable 1)
1
15 (max.)
Interface converter
RS-485 cable 3)
2
15 (max.)
MAX500m
