7.2 Preparatory Procedures for Monitoring
The following shows the procedures to be taken before monitoring and corresponding reference sections.
Confirming the PLC side setting
This section explains the GOT side setting.
When confirming the PLC side setting, refer to the following.
Section 7.3 PLC Side Settings
Install the OS onto the GOT.
Section 7.2.1
Installing OS onto GOT
Make sure that the OS is installed on the GOT.
Section 7.2.2
Checking OS installation on GOT
Set the communication interface. (Communication
settings)
Section 7.2.3
Setting communication interface
(Communication settings)
Download the project data.
Section 7.2.4
Downloading project data
Attach the communication unit and connect the cable.
Section 7.2.5
Attaching communication unit and
connecting cable
Make sure that the GOT recognizes the connected
equipment.
Section 7.2.6
Verifying GOT recognizes connected
equipment
Make sure that monitoring is performed normally.
Section 7.2.7
Checking for normal monitoring
