Mitsubishi GOT1000 Series User Manual

20 - 28
20.4 Temperature Controller Side Setting
20.4.1 Connecting E5AN, E5EN, E5CN, E5GN
20.4 Temperature Controller Side Setting
OMRON temperature controller
For details of OMRON temperature controller, refer to the following manual.
User's Manual for the OMRON temperature controller
20.4.1 Connecting E5AN, E5EN, E5CN, E5GN
Set the communication data by operating the key of the temperature controller.
*1 Make the same setting as that of the GOT side.
*2 Select the communication unit No. without overlapping with that of other units.
20.4.2 Connecting E5ZN
Set the communication data by operating the key of the temperature controller.
*1 Make the same setting as that of the GOT side.
*2 Select the communication unit No. without overlapping with that of other unit.
Model name Reference
Temperature controller
E5AN, E5EN, E5CN, E5GN Section 20.4.1
E5ZN Section 20.4.2
Interface converter K3SC-10 Section 20.4.3
Setting items Set value
Transmission speed
*1
9600bps, 19200bps
Data length
*1
8 bits, 7 bits
Parity bit
*1
Even, odd or none
Stop bit
*1
1 bit, 2 bits
Communication unit NO.
*2
0 to 99
Setting items Set value
Transmission speed
*1
9600bps, 38400bps
Data length
*1
8 bits, 7 bits
Parity bit
*1
Even, odd, none
Stop bit
*1
1 bit, 2 bits
Communication unit NO.
*2
0 to 15
