In trailer mode, theguide lines areshown at
thelevelofthe trailer hitch.
View of trailer (if trailer hitch is installed)
View of trailer (if trailer hitchisinstalled)
1
Yellowguide line, locating aid
2
Redguide line at adistance of approximately
1.0in(0.3 m) from theball head of thetrailer
hitch
3
Ball head of thetrailer hitch
Side viewofthe mirrorcameras
The sides of thevehicle can be seen in this view.
1
Lane indicating theroutethe vehicle will take
withthe steering wheel in its current position
2
Yellowwarning displayofParking Assist
PARKTRONIC: obstacles at adistance of
approximately 3.3 ft (1.0 m) or less
3
Your vehicle from above
4
Markerofthe wheel contact points
5
Guide line of external vehicle dimensions
withoutside mirrors folded out
If thedistance to theobject lessens, thecolor of
warning display 2 changes.
System failure
If thereisnooperational readiness, thefollowing
messageappearsinthe multimedia system:
System limitations
The 360°Camera will notfunction or will only
partiallyfunction in thefollowing situations:
R
The front doorsare open.
R
The side mirrors arefolded in.
R
Thereisheavy rain, snoworfog.
R
The ambient light is poor,e.g. at night.
R
The area is lit by fluorescent light (the display
mayflicker).
R
If thereisasudden changeintemperature,
e.g. when driving intoaheated garage in win‐
ter.
R
The ambient temperatureisveryhigh.
R
The cameralens is obstructed, dirty or fogged
up.
R
Cameras, or vehicle components in whichthe
cameras areinstalled, aredamaged. In this
event, have thecameras, their positionsand
their setting checkedataqualified specialist
workshop.
Do notuse the360° Cameraunder suchcircum‐
stances. Youcouldotherwise injureothersorcol‐
lide withobjects when parking thevehicle.
On vehicles withheight-adjustable suspension or
if thevehicle is carrying aheavy load, leaving the
standardheightcan result in inaccuracies in the
guide lines and in thedisplayofthe generated
images, depending on technicalconditions.
The field of vision and other functions of thecam‐
erasystemmay be restricted duetoadditional
attachments on thevehicle (e.g. loading tailgate).
%
The contrastofthe displaymay be impaired
by abruptdirect sunlight or by other light
sources, e.g. when driving out of agarage. In
this case, payparticular attention.
%
Have thedisplayrepaired or replaced if, for
example, pixel errors considerably restrict its
use.
