Switchoff thelighting system.
#
Place ascrewdriver,for example, at opening
2 between lamp 3 and panel 1 and care‐
fullypry offlamp 3.
#
Remove lamp 3 from panel 1.
#
Rotate thebulb holder by around 45°and
detach it from thelamp.
#
Remove thelight bulb.
#
Insertthe newbulb intothe bulb holder.
#
Insertthe bulb holder intothe lampand
rotate it by around 45°.
#
Insertthe lampintothe panel opening until it
engages.
Replacing rear light bulbs(chassis)
Overviewofrear bulbtypes (chassis)
Youcan changethe following bulbs.
Vehicles withstandardtail lamps
1
Clearance lamp: R5W
2
Tail light:R5W
3
Brakelight:P21W
4
Turn signals: PY 21 W
5
Reversing lights: P21W
6
Rear foglight (driver's side): P21W
7
License plate lamp: R5W
Replacing the taillamps on the chassis
Requirements:
R
Rear foglights: bulb type P21W
R
License plate lighting: bulb type R5W
R
Reversing lights: bulb type P21W
R
Turn signal indicators: bulb type PY 21 W
R
Clearance lamp: bulb type R5W
R
Brakelight: bulb type P21W
R
Taillight: bulb type R5W
1
Light lens
2
Screws
3
Rear foglight
4
License platelamp
5
Reversing light
6
Turn signal indicator
7
Clearance lamp
8
Brakelight
9
Taillight
#
Switch offthe lighting system.
#
Unscrew screws 1 and remove light lens
2.
#
Remove theplug connector from thelamp
carrier.
#
Gentlyturnthe bulb counter-clockwise and
take it out of thesocket.
#
Insert thenew bulb intothe socketand turnit
clockwise.
#
Position light lens 2 and tighten screws 1.
88
Light and vision
