Slowly insert dipstick 1 intothe dipstick
guide tube as farasitwillgoand pullitout
afterthree seconds.
R
Oil levelOK: theoil levelisbetween the
MIN and theMAX mark.
R
Oil leveltoo low: theoil levelisatthe MIN
markorbelow.
#
If theoil levelistoo low, add approx.
1.1USqt(1liter) engine oil.
#
If theoil levelistoo high, drain offexcess
engine oil.
Visit aqualified specialistworkshop.
Checking theengine oil levelwithanon-
boardcomputer
Requirements:
R
The vehicle is levelduring themeasuring
process.
R
The hood is notopen.
R
Dependingonthe driving profile, theoil level
can be displayedonlyafter adriving time of
up to 30 minutes and only when theignition
is switched on.
On-boardcomputer:
4
Service
5
Engine Oil Level
Youwillsee one of thefollowing messagesin
themultifunction display:
#
Measuring Engine Oil Level...:measurement
of theoil levelnot yetpossible. Repeat the
queryafter drivingamaximumof30minutes.
#
Engine Oil Level OK and thebar to displaythe
oil levelinthe multifunction displayisgreen
and lies between "MIN" and "MAX": theoil
levelisOK.
#
Engine Oil Level Drive until the engineis
warm.:warmupthe engine to operating tem‐
perature.
#
Engine Oil Level Correct Measurement Only
if VehicleIsonLevel Ground:parkthe vehicle
on an evensurface.
#
EngineOil Level Add 1,0 liq.gal. and thebar
to displaythe oil levelinthe multifunction dis‐
playisorangeand lies below"MIN": add
1.1USqt(1l)ofengine oil.
#
Reduce Engine Oil Level and thebar display‐
ing theoil levelinthe multifunction displayis
orangeand lies above "MAX": drain offexcess
engine oil.
Visit aqualified specialistworkshop.
#
For Engine Oil Level Switch Ignition On:
switchonthe ignition in order to checkthe
engine oil level.
#
Engine Oil Level System Inoperative:sensor is
defectiveornot connected. Visit aqualified
specialistworkshop.
#
Engine Oil Level System Currently Unavaila-
ble:close thehood.
%
Vehicles withcold oil leveldisplays:the oil
levelisautomaticallydisplayedonthe multi‐
function displayafter thevehicle has been
non-operational foranextendedperiod.Ifit
is notpossible to measure theengine oil
level, arelevant message will appear.
Adding engineoil
&
WARNING Risk of burnsfromhot com‐
ponent parts in theengine compartment
Certaincomponents in theengine compart‐
ment can be very hot, e.g. theengine, the
radiator and parts of theexhaust system.
#
Allowthe engine to cool down and only
touchcomponent parts described in the
following.
&
WARNING Danger of burnswhen open‐
ing thehood
If youopen thehood when theengine has
overheated or during afireinthe engine com‐
partment, youcouldcomeintocontact with
hotgases or other escaping operating fluids.
#
Beforeopening thehood, allowthe
engine to cool down.
#
In theevent of afireinthe engine com‐
partment, keep thehood closed and call
thefireservice.
If youhave to carry out anyworkinthe engine
compartment, touchonlythe following compo‐
nents:
R
Hood
R
Engine oil filler openingcap
R
Washer fluid reservoir cap
R
Coolant expansion reservoir cap
Maintenance and care
267
