Overviewofclimatecontrol systems
Heating system overview
1
Sets thetemperature
2
/Y Switches the
rear compartment heating
on/off
3
¤ Switches therear win‐
dowheater on/off
(/ page99)
4
O Switches footwell air
distribution on/off
5
¬ Switches windshield
defrosting on/off
(/ page98)
6
Vehicles withstationary
heater or heater booster:
& switches thestation‐
aryheater or heater boos‐
teron/off(/page101)
7
Vehicles with
windshield heating:
switches windshield heating
on/off(/page99)
8
Sets theairflow
%
The indicator lamps on thebuttons signal
that thefunction in question has been activa‐
ted.
