Place ascrewdriver intorecesses 2 and
then pryoff covers 1.
#
Using thelug wrenchfromthe vehicle tool kit,
unscrew thenow visible bolts counter-clock‐
wise by approximately20turns.
#
Slightly raise sparewheel carrier 4 and
unhook left-hand safetyhook 3.
#
Assemble thepumpleverfor thejackand
slide it intosleeve 5 on theright-hand side
of sparewheel carrier 4.
#
Raise sparewheel carrier 4 withthe pump
leverand unhook right-handsafetyhook 3.
#
Slowlylower sparewheelcarrier 4 to the
ground.
#
Lift sparewheel carrier 4 slightlyand pull
thepumpleverout of thesleeve.
#
Use thepumplevertoliftthe sparewheel
beyond therear edgeofsparewheel carrier
4.
#
Carefully remove thesparewheel from spare
wheel carrier 4.The sparewheel is heavy.
When thesparewheel is removed, thecenter
of gravity changes due to theheavy weight of
thewheel. The sparewheel mayslip down or
tip over.
Vehicles with rear wheel drive: installingthe
sparewheel (Cargo Van/Passenger Van)
#
Carefully place thesparewheel ontospare
wheel carrier 4.The sparewheel is heavy.
When youplacethe sparewheel ontospare
wheel carrier 4,the center of gravity
changes due to theweight of thewheel. The
sparewheel mayslip down or tip over.
#
Slide thepumpleverfor thejackintosleeve
5 on sparewheel carrier 4.
#
Raise sparewheel carrier 4 withthe pump
leverand attachright-hand safetyhook 3.
#
Slightly raise sparewheel carrier 4 and
attachleft-hand safetyhook 3.
#
Pull thepumpleverout of sleeve 5.
#
Using thelug wrench, tighten safetyhook
bolts 3 by turning them clockwise.
#
Replace and engagecovers 1.
#
Close therear-end doors.
Vehicles with rear wheel drive: removing the
sparewheel (vehiclewithlowered chassis)
Bolt covers forthe safetyhooks (example: Cargo
Van)
#
Openthe rear-enddoors.
Wheelsand tires
319
