5.2 Motor
5.2.1 Tr
ansporting and lifting
Note
Comply wit
h the local national regulations for the transportation of motors.
Requirement
• Use suitable load suspension de
vices when transporting and installing the motor.
• Do not lift the motor by the connector.
• Transport the motor carefully.
Procedure
Lifting and transporting the motor using slings
You can lift and transport the motor using lifting slings.
WARNING
Incorrectly dimensioned or incorrectly used lifting slings
If lifting slings are incor
rectly dimensioned or incorrectly used, the motor can fall and cause
death, severe injury and/or damage to property.
• Only use lifting slings that are suitable for the weight of the motor.
• Attach the lifting slings as shown in the gure "Lifting and transporting with lifting slings".
Mounting
5.2Motor
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 103
