7.4.4.4 Connection overview
Overview
Function view "Connection overview" provides information about the connections in the drive
system.
Description of function
The individual components with IP address and additional details are graphically displayed in the
connection overview.
Figure7-12 Connection overview
7.4.4.5 Communication
Overvie
w
Function view "Communication" provides information about the activated 󹪝eldbus interface.
Commissioning (web server)
7.4Functions and menus
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 193
