8.7 Con󹪝guring the con
verter
Overview
After carrying out the basic con󹪝guration of devices in the project, make the extended settings
for commissioning.
Description of function
The following areas are provided in display area "Parameterization":
• Basic parameterization
Here you can view the preassigned basic parameters of the converter, and if necessary you
can change individual values. If the motor brake is available, then you can also set that this
brake is forced open.
• Inputs/outputs
Here you can con󹪝gure the digital inputs and outputs of the converter.
• Technology functions
Here you con󹪝gure the basic positioner (EPOS) and pulse train output (PTO).
Note
Guided q
uick s
tartup
You can also easily con󹪝gure the settings of the basic parameterization and the digital inputs
using the guided quick startup (Page253).
Note
T
eleg
r
am con󹪝guration
You con󹪝gure the telegrams used in the converter con󹪝guration in the inspector window in the
telegram con󹪝guration. The most important settings are listed in Chapter "Con󹪝guring
telegrams (Page285)".
8.7.1 Basic parameterization
Ov
er
vie
w
You can parameterize the following operating parameters in the basic setting:
• Device supply voltage
• Direction of rotation
• Speed limit
• Torque limit
Commissioning (Startdrive)
8.7Con󹪝guring the conv
erter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
276 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
