8.3.5 Loading project data into the drive
Overvie
w
Load the data from your Startdrive project into a drive.
Requirement
• A project has been created.
• A drive has been created and completely con󹪝gured in the project.
• Optional: There is an active online connection between the converter and operating unit.
• For activated user management (UMAC):
The function rights for editing and loading drive data are activated for the user account.
Details on this topic are provided in Chapter "Security settings in Startdrive" of Industrial
Cybersecurity Con󹪝guration Manual (
https://support.industry.siemens.com/cs/ww/en/view/
109810578).
Procedure
Pr
oceed as follows to load the project data into your converter:
1. Select a drive in the project tree.
2. Click the
icon in the toolbar.
– If you ha
ve already established an online connection, then the "Load preview" dialog
opens.
This dialog displays alarms and proposes actions necessary for loading.
– If you have not established an online connection, then the "Extended loading" dialog
opens.
Using this dialog, establish an online connection to the required drive.
3. Check the messages in the "Load preview" dialog.
The "Save parameterization retentively" action is enabled by default.
4. Click "Load".
The project data are downloaded into the drive.
8.3.6 Saving changes in the project
Overview
Project data that are not saved are lost when closing the project. The entire project must be saved
in order for the settings to take e󹪜ect permanently.
Commissioning (Startdrive)
8.3Basics
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
226 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
