Requirement
• There is an online connection between the converter and the operating unit.
Diagnostic information can only be read out in the online mode.
• The user administration (UMAC) is activated for the project and converter. The following
applies:
The function rights required to read the converter data are activated for your user account.
Details on this topic are provided in Chapter "Security settings in Startdrive" of Industrial
Cybersecurity Conguration Manual (https://support.industry.siemens.com/cs/ww/en/view/
109810578).
Description of function
A
summary of the active security settings of the connected converter is displayed in diagnostics
view "Security".
• Logged-in user:
– The user that is logged into the converter.
OR
– No logged-in user, as UMAC is not active.
In this case, Siemens recommends that you activate UMAC.
• Ports & protocols:
Displays the activation state for the interfaces of the following areas:
– Web server access
– Fieldbus and associated protocols
– S7 commissioning reports
– DHCP conguration
• UMAC:
Shows certain UMAC settings which are activated for the converter. Shows, for example,
whether UMAC is active and what rights the user account "Anonymous" has.
You can only change the displayed security settings oine in the inspector window of the
converter in the project.
8.9.5 Communication
8.9.5.1 Receive direction
Overview
As standard, the components and interconnections of PROFIdrive telegrams in the receive
direction for the converter are displayed in this function view (e.g. 105 or 750).
You can add additional telegrams via the telegram conguration (
). The content of the
selected teleg
ram is then displayed in the "Supplementary data" area.
Commissioning (Startdrive)
8.9Using online diagnostic functions
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 299
