3.1.1 Converter
Description
The S200 converter product line (PN version) includes two converter variants: S200BasicPN
(200V only) and S200PN (200V and 400V).
All the converter variants can be used on the 1AC200V or 3AC 200V mains supply network
to control the 1FL2 motor with low or medium moments of inertia.
S200PN can additionally be used on the 3AC 400V mains supply network to control the
1FL2 motor with all the moments of inertia.
Table 3-1 Converter variants
Converter Frame size Rated power (kW) Mains supply network
S200BasicPN/S200PN FSA 0.1, 0.2 1 AC/3 AC 200 V ... 240 V
FSB 0.4
FSC 0.75, 1.0
S200PN FSA 0.2, 0.4 3AC380V...480V
FSB 0.75, 1.0
FSC 1.75, 2.5
FSD 3.5, 5.0, 7.0
Description
3.1System overview
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 43
