10.4.6.4 Control word for block selection
Overview
The block selection control word (SATZANW) activates the traversing block selection functions.
Description of function
Bit Function
0 1 = Traversing block selection, bit 0
1 1 = Traversing block selection, bit 1
2 1 = Traversing block selection, bit 2
3 1 = Traversing block selection, bit 3
4 1 = Traversing block selection, bit 4
5 1 = Traversing block selection, bit 5
6 Reserved
7 Reserved
8 Reserved
9 Reserved
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 1 = Activate MDI
0 = Deactiv
ate MDI
Functions
10.4Communication telegrams
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
350 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
