Status display after changes
Changes to individual se
ttings can also a󹪜ect settings in the guided quick startup. Status
symbols indicate the change state of the particular step
Table 8-2 Status symbols
Icon Meaning
The system defaults in this step are valid.
The settings made in this step are valid.
The se
ttings w
er
e made directly in this step, or are the consequences of settings in
another step.
The program changed the settings in this step. Possible causes are:
• Subsequent c
hanges were made in other steps, which are not automatically valid.
• The device con󹪝guration was subsequently changed. The changes in󹪞uence the
original settings.
Check the settings of this step.
More information
For mor
e information about guided quick startup, see the information system of the TIA Portal.
8.6.2 Editing mode (online only)
Overview
If you want to work with the guided quick startup in online mode, you need restore points in case
commissioning is aborted. Restore points are stored retentively on the SD card of the converter.
Restore points are automatically created when activating or exiting the editing mode and
also when switching from one step into the next step of the quick startup.
Note
Beha
vior when t
he online connection is t
erminated
If the connection to the drive is re-established after the online connection has been terminated,
the program reverts to the stored data of the last restore point.
Requirement
• The driv
e has been completely created and speci󹪝ed in the device con󹪝guration.
• If a control is also used, it must be connected to the drive in the topology view and in the
network view. The connection between the devices must also be con󹪝gured.
• There is an active online connection between the drive and the operating unit.
• No other access from another operating unit to the selected converter is active.
Commissioning (Startdrive)
8.6Carrying out guided quick startup
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
256 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
