Retentively saving oine data
When re
tentively saving data, it is important that the settings made are not only saved on
your operating unit in the Startdrive project, but also permanently saved on the SD card (also
known as "save retentively" or "RAM to ROM"). An online connection must be established to
the drive for this purpose.
Proceed as follows to save oine data retentively:
1. Establish an online connection to your drive.
2. Load the project data into your drive.
3. Click the
icon in the function view of the active Startdrive project.
The current pr
oject settings are stored retentively on the SD card of the drive.
8.3.8 Using parameter lists and user-dened lists
Overview
Users congure a drive in Startdrive as standard using specic conguration views. For the
conguration, experienced users preferably take the parameter lists or user‑dened lists.
Requirement
• For activated user management (UMAC):
The function rights for editing drive data are activated for your user account.
Details on this topic are provided in Chapter "Security settings in Startdrive" of Industrial
Cybersecurity Conguration Manual (
https://support.industry.siemens.com/cs/ww/en/view/
109810578).
Description of function
Par
ameter list
The following functions are available:
• Monitoring parameter values
• Editing parameter values directly from the parameter view
Only parameters with a light grey background can be directly edited in the parameter list.
Other parameters are locked in the parameter list and cannot be edited in the current
operating mode.
• Exporting parameters as CSV
• Comparing parameter settings:
– Oine - Factory setting
– Online - Oine
– Online - Factory setting
Commissioning (Startdrive)
8.3Basics
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
228 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
