Procedure
1. Activate the option "No synchronization, set time manually".
You can then choose whether to copy the time from your operating unit or enter the time
manually.
2. If you want to use the time from your operating unit, activate the option "Use time from PG/
PC".
Or
If you want to set the time manually, proceed as follows:
– In the "Drive time" area, set the current calendar day, the current year, and the desired
time.
– Select the time zone of your country in the "Time zone" area.
Example: For Central Europe, use the time zone "GMT+01:00".
3. Then click "Apply".
Result
The set time is directly transferred to the drive. The current time settings are displayed in the
"Current drive time" area.
8.9.7 Backup and restore
Overview
Perform the following actions in function view "Backup/Restore":
• Restart the drive now
• Retentively save the data in the converter
• Restore the drive data to factory settings
Security and interface settings are excluded.
8.9.7.1 Restarting the drive
Requirement
• There is an online connection between the project and the drive (see Chapter "Establishing
an online connection to the converter (Page288)").
• The drive is switched on and has voltage.
• For activated user management (UMAC):
The function rights required to edit the converter data are activated for your user account.
Details on this topic are provided in Chapter "Security settings in Startdrive" of Industrial
Cybersecurity Conguration Manual (https://support.industry.siemens.com/cs/ww/en/view/
109810578).
Commissioning (Startdrive)
8.9Using online diagnostic functions
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 305
