3.4.2 Cables and connectors
3.4.2.1 MOTION-C
ONNECT cables and connectors
Description
Siemens recommends that you use MOTION-CONNECT prefabricated cable assemblies and
connectors for connecting the motor to the converter. All Siemens cable assemblies and
connectors are tested and compliant with CE standards and EMC requirements.
Table 3-6 Overview of MOTION-CONNECT 350 and 380 cables
MOTION-CONNECT 350 and 380 cables Connectors
Type Article
number
6FX3☐02-
1)
Applicable
1FL2 mo
tor
Cr
oss-section for conductors
(mm
2
)
Drive
side
6FX2003
-
Motor
side
6FX2003-
Dual cable with hybrid connec‐
tor:
P
ower cable (with brake conduc‐
tors)
2)
+
encoder cable
7DD01-
☐☐☐☐
SH20
SH30
SH40
• Power cable (with brake con‐
ductors):
–
4×0.75+2×0.38
(4×18AWG+2×22AWG)
• Encoder cable:
– Cable length ≤ 15 m:
3×2×0.25
(3×2×24AWG)
– Cable length 20m or 30m:
2×2×0.25+2×0.38
(2×2×24AWG+2×22A
WG)
0DE61


3HD00
7DN01-
☐☐☐☐
3HN00
Dual cable with hybrid connec‐
tor:
P
ower cable (without brake con‐
ductors) +
encoder cable
7CD01-
☐☐☐☐
• P
ower cable (without brake con‐
duct
or
s):
– 4×0.75 (4×18AWG)
• Encoder cable:
– Cable length ≤ 15 m:
3×2×0.25
(3×2×24AWG)
– Cable length 20m or 30m:
2×2×0.25+2×0.38
(2×2×24AWG+2×22A
WG)
3HD00
7CN01-
☐☐☐☐
3HN00
Description
3.4Accessories
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
60 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
