4. Proceed as follows according to your selection:
– If you select "No. of PT
O pulses per motor revolution", enter the number of pulses per
motor revolution.
– If you select "Enter gear ratio", enter the gearbox ratio directly in the two input 󹪝elds above
and below the fraction bar.
The resulting pulses per revolution are calculated from this entry.
5. Save the settings in the project.
8.7.4 Con󹪝guring telegrams
8.7.4.1 Calling the telegram con󹪝guration
Overview
The "Telegram con󹪝guration" function is part of the device con󹪝guration, and is displayed in the
inspector window.
You can either call this function via the project tree or for Startdrive S drives, also via direct
links from the communication screen forms.
Information about the telegrams used in the converter is provided in "Communication
telegrams (Page332)".
Requirement
• The converter has been completely created and speci󹪝ed in the device con󹪝guration.
• For activated user management (UMAC):
The function rights required to con󹪝gure telegrams in the inspector window are activated for
your user role.
Details on this topic are provided in Chapter "Security settings in Startdrive" of Industrial
Cybersecurity Con󹪝guration Manual (
https://support.industry.siemens.com/cs/ww/en/view/
109810578).
Procedure
1
. Double-click the entry "Device con󹪝guration" in the project tree.
2. Click on the converter in the device con󹪝guration.
3. Click the entry "Telegram con󹪝guration" under "PROFINET interface [X150]" in the
"Properties" tab of the inspector window.
The settings for the telegram con󹪝guration are displayed below the respective 󹪝eldbus
interface.
Commissioning (Startdrive)
8.7Con󹪝guring the con
verter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 285
