7.2.4 Communication interfaces
Description
The f
ollowing interfaces are available for accessing the converter:
Interface Information
Service interface X127 The default access to the web server is via the service interface X127.
Ethernet interface X127 is intended for commissioning and diagnostics,
which means that it mus
t always be accessible.
Defaults:
• IP addres
s: 169.254.11.22
• Subnet mask: 255.255.0.0
• Data transfer via HTTPS is activated in the factory setting.
Restrictions:
• Only local acces
s is allowed.
• Only local networking in a closed and locked electrical cabinet is permis‐
sible.
• For remote access to the electrical cabinet, you must apply additional In‐
dustrial
Cybersecurity measures to prevent misuse through sabotage, data manip‐
ulation by unqualied persons and interception of condential data.
PROFINET interface
X150
• Converters are connected to several components, such as an operating
unit or a higher-lev
el control system, via PROFINET interface X150.
• The network at PROFINET interface X150 must be located in a secure pro‐
tection zone. Access to cables and open connections must be implemen‐
ted in a protected fashion, such as in a control cabinet.
• The IP addresses of the service interface X127 and the PROFINET interface
X150 must not be in the same subnet.
Commissioning (web server)
7.2Fundamentals
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 165
