14. REMOVE WATER BY–PASS PIPE
(a) Disconnect the two knock sensor connectors.
(b) Remove the two bolts, nut and water by–pass pipe.
15. REMOVE KNOCK SENSORS
Using SST, remove the two knock sensors.
SST 09816–30010
16. REMOVE NO.2 IDLER PULLEY BRACKET
Remove the three bolts and idler pulley bracket.
EG–100
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
