32. DISCONNECT RR ENGINE MOUNTING INSULATOR
(a) Remove the hole plugs.
(b) Remove the four nuts, and disconnect the mounting
insulator.
33. REMOVE ENGINE MOUNTING ABSORBER
Remove the four bolts and engine mounting absorber.
34. DISCONNECT FR ENGINE MOUNTING INSULATOR
Remove the three bolts, and disconnect the mounting insula-
tor.
35. ATTACH ENGINE SLING DEVICE TO ENGINE HANGERS
36. REMOVE ENGINE MOVING CONTROL ROD
Remove the three bolts and control rod.
EG–96
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
