WIRING DIAGRAM

Back Up Power Source Circuit

CIRCUIT DESCRIPTION

Battery voltage is supplied to terminal BATT of the ECM even when the ignition switch is off for use by the diag-

nostic trouble code memory and air–fuel ratio adaptive control value memory, etc.

DIAGNOSTIC CHART

DIAGNOSTIC

CHART

(See page EG–344).

EG–426

–ENGINE TROUBLESHOOTING CIRCUIT INSPECTION
