26. INSTALL NO.2 AND NO.3 RH ENGINE MOUNTING STAYS
(a) Install the No.2 RH engine mounting stay with the bolt and
nut.
Bolt
Torque: 75 N⋅m (760 kgf⋅cm, 55 ft⋅lbf)
Nut
Torque: 62 N⋅m (630 kgf⋅cm, 46 ft⋅lbf)
(b) Install the No.3 RH engine mounting stay with the two bolts.
Torque: 73 N⋅m (740 kgf⋅cm, 54 ft⋅lbf)
27. INSTALL ENGINE COOLANT RESERVOIR TANK
28. INSTALL WASHER TANK
(a) Connect the connector and vinyl hose to the washer tank.
(b) Install the washer tank with the three bolts.
29. INSTALL ENGINE COOLANT RESERVOIR HOSE
Connect the reservoir hose with the bolt.
30. CONNECT CABLE TO NEGATIVE TERMINAL OF
BATTERY
EG–46
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
