11. INSTALL DISTRIBUTOR (See IG section)
12. REMOVE ENGINE STAND
13. INSTALL REAR END PLATE
Install the end plate with the bolt.
Torque: 8.3 N⋅m (85 kgf⋅cm, 74 in.⋅lbf)
14. (M/T)
INSTALL FLYWHEEL
(a) Apply adhesive to two or three threads of the mount bolt end.
Adhesive:
Part No. 08833–00070, THREE BOND 1324 or equivalent
(b) Install the flywheel on the crankshaft.
(c) Install and uniformly tighten the eight mount bolts in several
passes, in the sequence shown.
Torque: 83 N⋅m (850 kgf⋅cm, 61 ft⋅lbf)
15. (A/T)
INSTALL DRIVE PLATE (See procedure step 14)
Torque: 83 N⋅m (850 kgf⋅cm, 61 ft⋅lbf)
16. (M/T)
INSTALL CLUTCH DISC AND COVER
EG–128
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
