STARTER INSTALLATION
ST01M–02
(See page ST–5)
1. INSTALL STARTER
(a) Install the starter with the two bolts.
Torque: 39 N⋅m (400 kgf⋅cm, 29 ft⋅lbf)
(b) Connect the starter wire with the nut.
(c) Connect the starter connector.
2. INSTALL CRUISE CONTROL ACTUATOR
(a) Install the cruise control actuator with the three bolts.
(b) Connect the actuator connector.
(c) Install the actuator cover.
3. INSTALL BATTERY
4. CONNECT CABLE TO NEGATIVE TERMINAL OF
BATTERY
5. CHECK THAT ENGINE STARTS
ST–18
–STARTING SYSTEM STARTER
