37. REMOVE ENGINE AND TRANSAXLE ASSEMBLY FROM
VEHICLE
(a) Lift the engine out of the vehicle slowly and carefully.
NOTICE: Be careful not to hit the PS gear housing or
park/neutral position switch (A/T).
(b) Make sure the engine is clear of all wiring, hoses and cables.
(c) Place the engine and transaxle assembly onto the stand.
38. (A/T)
REMOVE STARTER
39. SEPARATE ENGINE AND TRANSAXLE
M/T (See MT section)
A/T (See AT section)
40. REMOVE NO.2 RH ENGINE MOUNTING BRACKET
Remove the three bolts and nut, RH engine mounting stays
and engine mounting bracket.
41. REMOVE FR ENGINE MOUNTING INSULATOR
Remove the three bolts and mounting insulator.
42. REMOVE RR ENGINE MOUNTING INSULATOR
Remove the four bolts and mounting insulator.
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
EG–97
