TIMING BELT REMOVAL
EG0F0–02
1. DISCONNECT CABLE FROM NEGATIVE TERMINAL OF
BATTERY
CAUTION (w/ Airbag): Work must be started after approx.
30 seconds or longer from the time the ignition switch is
turned to the ”LOCK” position and the negative (–) termi-
nal cable is disconnected from the battery.
2. DISCONNECT ENGINE COOLANT RESERVOIR HOSE
Remove the bolt and disconnect the reservoir hose.
3. REMOVE WASHER TANK
(a) Remove the three washer tank mounting bolts.
(b) Disconnect the connector and hose, and remove the washer
tank.
4. REMOVE ENGINE COOLANT RESERVOIR TANK
Using a screwdriver, remove the reservoir tank.
5. REMOVE NO.2 AND NO.3 RH MOUNTING STAYS
(a) Remove the two bolts and No.3 RH engine mounting stay.
(b) Remove the bolt, nut and No.2 RH engine mounting stay.
EG–30
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
