CYLINDER HEADS DISASSEMBLY
EG0F5–01
(See page EG–47)
1. REMOVE VALVE LIFTERS AND SHIMS
HINT: Arrange the valve lifters and shims in correct order.
2. REMOVE VALVES
(a) Using SST, compress the valve spring and remove the two
keepers.
SST 09202–70010
(b) Remove the spring retainer, valve spring, valve and spring
seat.
HINT: Arrange the valves, valve springs, spring seats and
spring retainers in correct order.
(c) Using needle–nose pliers, remove the oil seal.
EG–60
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
