IAC VALVE INSTALLATION
EG0HC–01
(See page EG–210)
1. INSTALL IAC VALVE
(a) Install a new gasket and the IAC valve with the two bolts.
Torque: 13 N⋅m (130 kgf⋅cm, 9 ft⋅lbf)
2. CONNECT PS IDLE UP VACUUM HOSE
3. CONNECT TWO WATER BY–PASS HOSES
4. CONNECT TWO AIR HOSES
5. CONNECT IAC VALVE CONNECTOR
6. FILL WITH ENGINE COOLANT
7. CONNECT CABLE TO NEGATIVE TERMINAL OF
BATTERY
–ENGINE TROUBLESHOOTING SFI SYSTEM
EG–213
