4. CONNECT HOSES TO OIL COOLER
Connect the following hoses:
(1) Outlet hose (to reservoir)
(2) Inlet hose (from hydraulic motor)
5. INSTALL RH HEADLIGHT ASSEMBLY
(a) Connect the three connectors.
(b) Install the headlight assembly with the three bolts.
6. INSTALL UPPER RADIATOR SUPPORT SEAL
Install the support seal with the ten clips.
7. FILL PS RESERVOIR TANK WITH FLUID
(See page EG–264)
8. BLEED ELECTRONICALLY CONTROLLED HYDRAULIC
COOLING FAN SYSTEM
(See page EG–265)
EG–280
–ENGINE TROUBLESHOOTING COOLING SYSTEM
