PREPARATION FOR DISASSEMBLY
EG0FA–01
1. (M/T)
REMOVE CLUTCH COVER AND DISC
2. (M/T)
REMOVE FLYWHEEL
3. (A/T)
REMOVE DRIVE PLATE
4. REMOVE REAR END PLATE
Remove the bolt and end plate.
5. INSTALL ENGINE TO ENGINE STAND FOR
DISASSEMBLY
6. REMOVE DISTRIBUTOR (See IG section)
7. REMOVE TIMING BELT AND PULLEYS
(See page EG–29)
8. REMOVE CYLINDER HEADS
(See page EG–47)
9. REMOVE WATER PUMP (See page EG–246)
10. REMOVE OIL PAN AND OIL PUMP
(See page EG–294)
11. REMOVE OIL FILTER AND FILTER BRACKET
(See page EG–307)
12. REMOVE OIL PRESSURE SWITCH
Using SST, remove the oil pressure switch.
SST 09816–30010
13. REMOVE ENGINE COOLANT DRAIN COCK
(a) Remove the water drain hose.
(b) Remove the bolt and hose clamp.
(c) Remove the drain cock.
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
EG–99
