1. DISCONNECT CABLE FROM NEGATIVE TERMINAL OF
BATTERY
CAUTION (w/ Airbag): Work must be started after approx.
30 seconds or longer from the time the ignition switch is
turned to the ”LOCK” position and the negative (–) termi-
nal cable is disconnected from the battery.
2. REMOVE BATTERY AND TRAY
3. REMOVE HOOD
4. REMOVE ENGINE UNDER COVER
5. DRAIN ENGINE COOLANT
6. DRAIN ENGINE OIL
7. DISCONNECT ACCELERATOR CABLE FROM
THROTTLE BODY
8. (A/T)
DISCONNECT THROTTLE CABLE FROM THROTTLE
BODY
9. REMOVE AIR CLEANER ASSEMBLY, VOLUME AIR
FLOW METER AND AIR CLEANER HOSE
(a) Disconnect the volume air flow meter connector.
(b) Disconnect the IAC valve and PCV hoses.
(c) Loosen the air cleaner hose clamp bolt.
(d) Disconnect the four air cleaner cap clips.
(e) Disconnect the air cleaner hose from the throttle body, and
remove the air cleaner cap together with the volume air flow
meter and air cleaner hose.
(f) Remove the air filter.
(g) Remove the three bolts and air cleaner case.
10. REMOVE CRUISE CONTROL ACTUATOR
(a) Remove the actuator cover.
(b) Disconnect the actuator connector.
(c) Remove the three bolts, and disconnect the actuator with the
bracket.
11. DISCONNECT GROUND STRAP FROM BATTERY
CARRIER
12. REMOVE RADIATOR
EG–90
–ENGINE TROUBLESHOOTING ENGINE MECHANICAL
