SECTION 4
4-15
CAUTION:
If the blockage cannot be removed by the
header reversing system, stop the engine
before attempting to unplug the header
manually.
6. Grain headers only
Slowly move the crop with the reel to the feed
auger.
7. Continue operation.
HEADER AND/OR STRA W ELEVATOR BLOCK-
AGE -- MANUAL CLEARING
CAUTION:
If the blockage cannot be removed by
means of the reversing system, disen-
gage all engagement systems, shut down
the engine and wait until all parts have
come to a standstill.
If the blockage is situated at the straw elevator upper
shaft, gain access through the straw elevator bottom
plate. Refer to the paragraph below.
If the blockage is situated at the straw elevator bottom
shaft, it will be necessary to detach the header. Refer
to Section 2, paragraph headed ‘‘Detaching the head-
er from the combine’’.
REEL TO GROUND SPEED SYNCHRONIZATION
With switch 43 (Fig.15) in the ON position, the reel
speed is synchronized to the ground speed. The ba-
sic ratio between the reel and the ground speed is
memorized in the central processing unit (part of the
fuse box). However, this ratio can be increased or de-
creased with the reel speed control switch 12
(Fig.13). The new ratio result will automatically be
memorized, replacing the existing ratio (still with
switch 43 in the ON position).
