SECTION 1
1-25
Access protection to engine compartment --
Figure 27
Lowering the ladder 5 while the engine is running will
automatically cause the engine to be shut off. It is,
however , possible to start the engine while the ladder
is in the lowered position.
IMPORTANT:
Be aware that, if the engine is running with the
ladder in the lowered position, the engine
protection is not working.
43039
27
INTENDED USE
The TX60 Series combine harvesters are designed
as self-propelled units and are powered by an
on-board diesel engine.
The machines are intended to be used for agricultural
purposes on cultivated land to harvest cereal crops,
small seed crops, maize, soy beans, etc., by cutting
or picking up from a swath, threshing and separating
the grain from the straw and temporarily storing it until
it is unloaded into vehicles for transport.
