FIELD OPERATION
4-58
4 -- AREA COUNTER MODE -- Figure 95
The area counter mode as well as the r pm mode is
used during field operation to c ontrol the different
combining parameters described below.
NOTE:
In the area counter mode the engine load bar-
graph A and the performance bargraph B (or
returns capacity bargraph) are displayed as
well.
Refer to paragraphs 3.1 to 3.3.
Press
to switch from rpm to area counter
mode, or vice versa.
4.1 Threshing drum hours F -- Figure 96
This counter shows the time the threshing
mechanism has been engaged since the area counter
mode was last c leared (Refer to paragraph 5
‘‘Memory Mode’’.
54776
54775
95
96
