SECTION 4
4-83
n) Figure 121 -- Appearing:
‘‘CONCAVE CLOSED AND PUSH ENTER’’
Now raise the concave completely.
At its end-of-stroke, press
to validate
this position.
The calibration procedure will automatically
continue with step o).
On units equipped with a flex header control
printed circuit, continue with step r.
o) Figure 122 -- Appearing:
‘‘AUTOMATIC COMP.: YES’’
S When the combine is equipped with au-
tomatic header compensation, select :
‘‘AUTOMATIC COMP.: YES’’ by pressing
or , and to validate.
The calibration procedure will automati-
cally continue with step r.
S When selecting ‘‘AUTOMATIC COMP.:
NO’’ (TX62 option), the calibration proce-
dure will automatically continue with step
p).
48188
121
52226
122
