OPERATION
2-12
W ARNING:
S Model TX62
When the ignition key is switched on,
it is possible to reverse the straw ele-
vator operation without the engine
running (electrical motor).
S Model TX63
Ensure the header and straw elevator
reversing switch is in the OFF position
when starting the combine, otherwise
the straw elevator would start revers-
ing immediately after starting th e
combine.
The concave clearance i
shown on the InfoVie
monitor.
45 Models T
64
PLUS
-65
PLUS
66-67- 68-68
PLUS
Drum concave control
rocker switch
+ (open) = lower concave
Neutral
-- (close) = lift concave
46 Header vertical kni
etum-
bler switch [if installed]
D
47
Operating lights tumble
switch
OFF
(a) close angle
(b) far angle
OFF
Vertical right-hand knife
ON
Both vertical knives ON
(red plastic window)
T win operating lights on front railing (ref. 123)
Operating lights on cab (ref. 122) OFF ON
Stubble lights (ref. 126) [if installed] ON OFF
Adjustable spotlight on engine railing [if installed]
(ref. 130)
NOTE:
Only when unloading tube is in open position.
ON ON
Right-hand side operating light (ref. 124) ON OFF
ON ONGrain tank light (ref. 131)
Position (a) Position (b)
ON
(inner & outer)
ON
(only inner)
Operating lights tumbler switch summary
(only with ignition switch 52 on)
ON OFFRear light (ref. 130a) [if installed]
