SECTION 1
1-23
Safety guards -- Figure 21
For safety’s sake and according to European
directives, safety guards now have locking devices
which can only be opened by means of the special
tool located on the left-hand side of the straw elevator,
a wrench (key width 13 mm) or a screw driver.
Straw chopper spreader chute -- Figure 22
The straw chopper spreader chute A must remain in
the operating position (as shown) when driving on
public roads when the combine is not pulling a header
trailer.
Fire extinguisher -- Figure 23
The fire extinguisher is located on the left-hand side
near the straw hood.
Check the operating instructions.
Once the extinguisher is discharged, no matter for
how long, it must be recharged.
43037
21
30355
42965
22
23
