SECTION 4
4-57
3.5 Ground, cleaning fan or engine speed D --
Figure 93
Press
to display the ground speed which is ad-
justabe with the ground speed control lever and the
gearshift lever.
Press
to display the cleaning fan speed wich
is abjustable with the cleaning fan rocker switch.
Press
to display the engine speed. Adjust with
the engine speed rocker switch.
When starting up the InfoView monitor, the ground
speed will be displayed.
The ground speed will automatically be displayed
when the combine ground speed is higher than 20
km/h for a period of 20 seconds.
3.6 Concave clearance E -- Figure 94
The c urrent concave clearance E is shown and can be
adjusted with the concave clearance rocker switch
(from 3 to 51 mm).
54774
52693
93
94
