TROUBLESHOOTING
6-14
HYDRAULIC VALVE ELECTRICS - Models TX64
PLUS
-65
PLUS
-66-67-68-68
PLUS
-- Figure 2
CONCERN POSSIBLE CAUSE CORRECTION PAGE
Header/straw elevator (A),
threshing mechanism (C)
or unloading system (B)
not engaging.
No current to spool.
Check and replace fuse, if
needed.
Open the unloading tube to +
90° position (should not be in
contact with the end-of-
stroke switch on t he tube col-
lar).
Remove one plug of the tube
position control valve (H) and
plug in the engaging valve
needed.
Engage the unloading tube
position switch in the required
position (up or down).
5-57
Fig. 2
42904
2
