New Holland TX62 User Manual

9
FUSES
The two following decals explain the use and amperage of each fuse.
Please cut out both decals and adhere them to the inner side of the access door
to the electric box on each side of the print containing the fuses.
This will facilitate troubleshooting.
Fuse
Amp. Function Fuse Amp. Function
F1 15A Brush in rotary screen [if installed] F13 10A Air conditioning compressor clutch
F2 25A Light switch
Sockets, left and right-hand side
F14 25A Air conditioning fan
F3 15A Flashing warning lights F15 25A Socket-vertical knife, right-hand side
F4 10A Socket on straw hood, right-hand side F16 25A Socket-vertical knife, left-hand side
F5 15A Parking lights, right-hand side F17 15A Dipped headlights
F6 15A Parking light, left-hand side F18 15A Headlights
F7 -- -- F19 10A Header height control
F8 15A Operating lights on railing (outer side of light)/
operating lights on cab
F20 25A Stubble light + side light
F9 25A Wiper, mirrors F21 15A Operating lights on railing (inner side of lights) +
light in grain tank
F10 10A Direction indicator lights F22 10A Light on unloading tube
F11 15A Stop lights -- Horn F23 15A Plugs, Radio, CB, Clock, Light in cab
F12 10A Relay: -- Operating lights on railing
(inner side of light)
-- Light in grain tank
-- Stubble lights + side lights/
operating light on unloading tube
F24 10A Threshing mechanism
Central process unit
Header height adjustment
Fuse Amp. Function Fuse Amp. Function
F25 10A Levelling system F34 10A
25A
Engagement of threshing, unloading and header
mechanism (models TX64 to TX68
PLUS
)
Reversing mechanism actuator (Model TX62)
F26 25A Drum variator
Fan varia to r
Spread plates on straw chopper
F35 25A Straw chopper clutch
Reversing mechanism actuator (not for model
TX62)
Manual lateral float
Header height control module
Reel horizontal control
F27 10A Central process unit F36 10A Relay to unloading and header mechanism
Reel vertical movement switch
Reel variator
Engine kill stop
F28 25A Powered rear axle
Throttle mechanism
Parking brake
Reel synchronization
F37 10A Ignition switch
F29 10A Valves for: -- Opening unloading auger
-- Reel lift
-- Pilot valve
F38 -- --
F30 10A InfoView monitor display
Lighting of dashboard switches
F39 -- --
F31 15A Engine protection
Hydrostatic control
Led indicators on dashboard
Remote gearshift printed circuit, remote parking
brake and quick stop
F40 -- --
F32 25A Reel variator motor F41 40A Automatic fuse for levelling system
F33 15A Traffic warning lights
(Ref. to Print N° 604.63.021.00
3rd Edition
English 09/98)
