SECTION 4
4-87
S At the bottom of the display appears --
Figure 130: ‘‘CAL/SET COMPLETE’’.
This means line 1 is now completely cali-
brated. After 5 seconds the monitor will
return to the rpm mode as shown in Fig-
ure 84.
NOTE:
This is the c ase after a complete cal-
ibration of each selection line (when
‘‘CAL/SET COMPLETE’’ is shown) or
when pressing
after a specific
item calibration is confirmed (by
pressing
).
Line 2 -- HEADER -- Figure 131
1. Enter the calibration mode by pressing
.
2. Select line 2 ( ‘‘HEADER’’) by pressing
or
, and to validate the choice.
52334
SET CONTRAST LCD AND
PUSH ENTER
130
48154
131
